AquaForce® - 30XW-V

Variable-speed water-cooled screw chiller

The 30XW-V water-sourced units are designed for commercial and industrial applications where installers, consultants and building owners require high performance, particularly at part load.

  • Designed to optimise energy use
  • Designed for reliable operation
  • Easy and fast installation
  • Minimised operating sound levels
  • Supports emissions reduction goals
  • Designed for high-efficiency building applications
Refrigerant :
R-134a
Compressor :
screw variable-speed
Nominal cooling capacity :
590-1,740 kW
Efficiency :
High
Application :
Office building, Hotel & Leisure, Healthcare, Industry, Education

Features & Benefits

  • Designed for high performance both at full load and at part load
  • SEPR up to 10.7 and SEER up to 8.8
  • Inverter-driven twin-rotor screw compressors allow precise capacity matching of building load changes and reduce unit power input, especially at part-load
  • Flooded multi-pipe heat exchangers for increased heat exchange efficiency
  • Electronic expansion device permitting operation at a lower condensing pressure and improved utilisation of the evaporator heat exchange surface
  • Optimised electrical performance
  • Supports overall system performance
  • Inverter-driven screw compressors with oversized bearings and motor cooled by suction gas (liquid cooled motor on 1401 & 1601 models). The inverter is optimised for each compressor motor to ensure reliable operation and easy maintenance
  • Two independent refrigerant circuits
  • Auto-adaptive control
  • Extensive endurance testing
  • Compact design
  • Simplified electrical connections
  • Simplified water connections
  • Fast commissioning
  • R-134a refrigerant
  • Leak-tight refrigerant circuit
  • Low noise Greenspeed® variable-speed fans
  • The inverter technology used for the compressor motors minimises noise levels at part load operation
  • Silencers on the compressor discharge line
  • Sound insulation on the components that are most subjected to radiated noise
  • Option 257 further reduces the global unit sound level
  • Building cooling loads can vary significantly throughout the year, requiring systems capable of maintaining efficient operation across a wide operating range. Selecting an air-conditioning system that delivers strong performance at both full and part load is an important consideration for many commercial and industrial projects.
  • The 30XW-V unit is designed to address these operating conditions through inverter-driven screw compressor technology, precise capacity control and high part-load efficiency. By continuously matching cooling capacity to building demand, the unit helps maintain efficient operation under varying load conditions.
  • Combining advanced control capabilities with high seasonal efficiency, the 30XW-V provides a solution for applications where energy performance, operational reliability and occupant comfort are key project requirements.
  • Advanced control algorithms combine inverter frequency output with motor input logic to minimise mechanical part stress, resulting in high compression performance and high chiller reliability
  • Equipped with bearings with oversized rollers, oil pressure lubricated for reliable and durable operation, even at maximum load
  • Screw compressors use positive displacement principle to compress gases at higher pressure. As a result, in case of exceptional high temperature condenser side, the compressor does not switch off, but continues operation at reduced capacity (unloaded mode)
  • The silencer in the discharge line considerably reduces discharge gas pulsations for much quieter operation
  • Condenser includes an oil separator that minimises the amount of oil in circulation in the refrigerant circuit and redirects it to the compressor function



Controls

  • An intuitive user-friendly coloured 7" interface
  • Direct access to the unit's technical drawings and the main service documents
  • Screen-shots with coincisive and clear information in local languages
  • Complete menu, customised for different users
  • Safe operation and unit setting: password protection ensures that unauthorised people cannot modify any advanced parameters
  • Simple and "smart" intelligence uses data collection from the constant monitoring of all machine parameters to optimise unit operation
  • Energy management
