- SEPR up to 8.0 and SEER up to 7.2
- Twin-rotor screw compressor equipped with a high efficiency motor and a variable capacity valve that permits exact matching of the cooling capacity to the load
- Flooded multi-pipe heat exchangers for increased heat exchange efficiency
- Electronic expansion device permitting operation at a lower condensing pressure and improved utilisation of the evaporator heat exchange surface
- Economiser system with electronic expansion device for increased cooling capacity (30XW-P)
AquaForce® - 30XW / 30XW-P
Fixed-speed water-cooled screw liquid chiller
The 30XW liquid chillers are designed for industrial and commercial applications where installers, consultants and building owners require high performance and proven reliability.
- Designed to optimise energy use
- Designed for reliable operation
- Easy and fast installation
- Low operating sound levels
- Supports emissions reduction goals
- Refrigerant :
- R-134a
- Compressor :
- screw fixed-speed
- Nominal cooling capacity :
- 270-1,760 kW
- Efficiency :
- High, Standard
- Application :
- Office building, Hotel & Leisure, Healthcare, Industry, Education, Marine
Features & Benefits
- Silencers on the compressors discharge line
- Silencers on the economiser return line
- Acoustic insulation on the components that are most subjected to radiated noise
- Option 257 further reduces the global unit sound level
- R-134a refrigerant
- Leak-tight refrigerant circuit
- Supports overall system performance
- Major components are selected and tested to minimise failures possibility, as well as many design choices have been taken in this perspective
- Industrial-type screw compressors with oversized bearings and motor cooled by suction gas
- Two independent refrigerant circuits
- Auto-adaptive control
- Extensive endurance tests
- Equipped with bearings with oversized rollers, oil pressure lubricated for reliable and durable operation, even at maximum load
- Precise adjustment of the compressor cooling capacity
- If a fault occurs, the compressor does not switch off, but continues operation with a reduced capacity (unloaded mode)
- The silencer in the discharge line reduces discharge gas pulsations for quieter operation
- Condenser includes an oil separator that minimises the amount of oil in circulation in the refrigerant circuit and redirects it to the compressor function
Controls
SmartVu™ control
- Intuitive and user-friendly, coloured, 4.3" interface
- 10 languages available
- Easy access to the controller box
- Password protection
- Night-modex
- Energy management
Options
- Medium- or low-temperature brine solution
- Light-brine solution, down to -3°C
- Unit supplied in two assembled parts
- Lead/lag operation
- Single power connection point
- No disconnect switch, but short circuit protection
- Condenser insulation
- J-Bus gateway
- BacNet over IP gateway
- Lon gateway
- High condensing temperature
- Leak detection
